Losing power means disruption from the internet, business meetings, and data processing and can even restrict you from contacting family and friends. APC by Schneider Electric BVX2200LI provides continuous power to your devices to ensure your devices remain protected.
Power outages, voltage fluctuations, and electrical surges can wreak havoc on critical equipment, leading to data loss, downtime, and significant financial losses. That’s where the BVX2200LI APC Easy UPS BVX 2200VA comes in. This cutting-edge power backup solution provides reliable and efficient power protection for your valuable devices. In this blog post, we will delve into the features and benefits of the BVX2200LI APC Easy UPS, highlighting its key functionalities and explaining why it’s a must-have for businesses seeking uncompromised power reliability.
PROVIDED EQUIPMENT |
User manual
|
|
---|---|---|
MAX RUNTIME |
240Â min
|
|
NUMBER OF TARE POWER |
30Â W
|
|
NUMBER OF POWER MODULE FREE SLOTS |
0
|
|
NUMBER OF POWER MODULE-FILLED SLOTS |
0
|
|
REDUNDANT |
No
|
|
UPS SIZE |
WS
|
CABLE LENGTH |
1.22Â m
|
|
---|---|---|
COLOUR |
Black
|
|
DEPTH |
39Â cm
|
|
HEIGHT |
19Â cm
|
|
MOUNTING SUPPORT |
Floor
|
|
MOUNTING PREFERENCE |
No preference
|
|
NET WEIGHT |
12.2Â kg
|
|
MOUNTING MODE |
Not rack-mountable
|
|
TWO POST MOUNTABLE |
0
|
|
USB COMPATIBLE |
No
|
|
WIDTH |
14Â cm
|
NETWORK FREQUENCY |
50/60 Hz +/- 5 Hz auto-sensing
|
|
---|---|---|
PLUG STANDARD |
IEC 60320 C20
|
|
INPUT VOLTAGE LIMITS |
140…300 V 230 V AC
|
|
NUMBER OF CABLES |
1
|
|
INPUT VOLTAGE |
230 V AC 1 phase
|
|
COS PHI |
0.54
|
RATED POWER IN W |
1200Â W
|
|
---|---|---|
MAXIMUM CONFIGURABLE POWER IN W |
1200Â W
|
|
OUTPUT FREQUENCY |
50/60 Hz +/- 1 Hz sync to mains
|
|
UPS TYPE |
Line Interactive
|
|
WAVE TYPE |
Stepped approximation to a sinewave
|
|
NB OF POWER SOCKET OUTLETS |
6 IEC 320 C19
|
|
CURVE EQUATION |
Efficiency
|
|
CURVE FIXED LOSS |
0.0195
|
|
CURVE LOAD MAXIMUM |
100Â %
|
|
CURVE LOAD MINIMUM |
2Â %
|
|
CURVE PROPORTIONAL LOSS |
0
|
|
CURVE SQUARE LOSS |
0.0102
|
|
CURVE X-AXIS MAXIMUM |
100Â %
|
|
CURVE TEST COND ID |
Curve fit of data measured by the ENERGY STAR Test Method for Uninterruptible Power Supplies. All measurements taken in normal mode(s), at typical environmental conditions, with 230V/50Hz electrical input and balanced resistive load (PF =
|
|
CURVE X-AXIS MINIMUM |
0Â %
|
|
CURVE X-AXIS TITLE |
Load
|
|
CURVE X-AXIS UNITS |
Percentage
|
|
CURVE Y-AXIS MAXIMUM |
100Â %
|
|
CURVE Y-AXIS MINIMUM |
50Â %
|
|
CURVE Y-AXIS TITLE |
Efficiency
|
|
CURVE Y-AXIS UNITS |
Percentage
|
|
FULL LOAD RUNTIME |
00:01:00 1200 W
|
|
GRAPH DISPLAY |
1
|
|
HALF LOAD RUNTIME |
00:08:30 600 W
|
|
OUTPUT VOLTAGE |
230 V AC 1 phase
|
|
MAXIMUM CONFIGURABLE POWER IN VA |
2200Â VA
|
|
RATED POWER IN VA |
2200Â VA
|
|
TRANSFER TIME |
6 ms typical: 10 ms maximum
|
PRODUCT CERTIFICATIONS |
CE
CB |
|
---|---|---|
STANDARDS |
CE
EN/IEC 62040-1 EN/IEC 62040-2 |
|
EQUIPMENT PROTECTION POLICY |
Lifetime: 50000 euros
|
AMBIENT AIR TEMPERATURE FOR OPERATION |
0…40 °C
|
|
---|---|---|
RELATIVE HUMIDITY |
0…95 % non-condensing
|
|
OPERATING ALTITUDE |
0…3000 m
|
|
AMBIENT AIR TEMPERATURE FOR STORAGE |
-15…40 °C
|
|
STORAGE RELATIVE HUMIDITY |
0…95 % Non-condensing
|
|
STORAGE ALTITUDE |
0…3000 m
|
|
ACOUSTIC LEVEL |
40 dBA
|
|
SHOW NOTE OP TEMPERATURE |
No
|
|
IP DEGREE OF PROTECTION |
IP20
|
BATTERY TYPE |
Lead-acid battery
|
|
---|---|---|
NUMBER OF BATTERY-FILLED SLOTS |
0
|
|
NUMBER OF BATTERY-FREE SLOTS |
0
|
|
BATTERY RECHARGE TIME |
8Â h
|
|
LIQUID VALUE |
0
|
|
BATTERY VOLTAGE |
24 V
|
|
BATTERY CAPACITY |
9.0Â Ah
|
|
BATTERY CURVE |
C
|
|
BATTERY POWER IN VAH |
190 VAh runtime
216 VAh capacity |
|
BATTERY LIFE |
1…2 year(s)
|
|
BATTERY GRAPH COMMENTS |
Curve fit to measured runtime data. All measurements were taken with new, fully charged batteries, at typical environmental conditions, with no electrical input and balanced resistive load (PF = 1.0) output.
|
|
EXTENDED RUNTIME |
0
|
CONTROL PANEL |
LED Status display online: on battery
|
|
---|---|---|
ALARM |
Alarm when on battery: distinctive low battery alarm
|
SURGE ENERGY RATE |
273Â J
|
---|
PACKAGE 1 WEIGHT |
13.2Â kg
|
|
---|---|---|
PACKAGE 1 HEIGHT |
29.7Â cm
|
|
PACKAGE 1 WIDTH |
23.5Â cm
|
|
PACKAGE 1 LENGTH |
49.5Â cm
|
|
SCC14 |
10731304404528
|
EU ROHS DIRECTIVE |
Compliant
EU RoHS Declaration |
---|
WARRANTY |
2 years repair or replace
|
---|
