Hammer CPS6004 4-Zone Electric Fence Energizer

The CPS range of energisers are the zoned energisers which are fully programmable with the included keypad. We offer a dual zone and 4 zone energiser unit. The CPS RANGE is a compact, integrated electric fence energiser and alarm monitor unit with remote LCD keypad control.

The unit employs state of the art microprocessor and surface mount technology. A unique feature of the CPS Range is the innovative SMARTLINK concept. A security weakness of all energisers on the market at present is that the high voltage, output wire and return wire, can be bridged across at the point they connect to the fence. The rest of the fence can then be disconnected, without triggering the alarm, since the return pulse will still be detected. The SMARTLINK prevents this from happening.

The CPS6000 range consists of two models including the dual high voltage zones (6002), and the quad high voltage zones (6004). These zones are hard wired zones, each wired directly from the energiser. The dual and quad zone units have been designed with a separate high voltage transformer for each zone, so that if one zone is shorted then the other zones still have power. The LCD keypad is used to display system information and to control the energiser. The system is also programmable from the keypad and was designed for ease of installation and maximum security.

Product Features

• Fully programmable with keypad
• High voltage live line monitoring with alarm.
• Earth line monitoring with alarm via Smartlink
• Gate (Auxiliary) monitoring with alarm.
• Siren and Strobe connections
• Battery backup
• Solar enabled
• Lightning and power surge suppression built-in.
• Comes with easy to use LCD keypad
• Multiple keypads can be added
• Optional extra-alarm outputs per zone
